HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
HD 13i VT
  • Excellent view of drum edge, machine and construction site environment
  • Ergonomic driver platform
  • Compact dimensions
  • Simple transport, simple loading
  • Simple, intuitive and language-neutral control

Specifications

BASIC DATA - Description:
Tandem roller with vibrating roller drum and set of wheels
BASIC DATA - Exhaust emissions category:
EU Stage V / EPA Tier 4
BASIC DATA - Name:
HD 13i VT
BASIC DATA - Series:
H285
DIESEL ENGINE - Cylinders, quantity:
4
DIESEL ENGINE - Exhaust emission standard:
EU Stage V / EPA Tier 4
DIESEL ENGINE - Exhaust gas after-treatment:
DOC-DPF
DIESEL ENGINE - Manufacturer:
KUBOTA
DIESEL ENGINE - Model:
V2403-CR-E5B
DIESEL ENGINE - Power ISO 14396, HP:
50 HP
DIESEL ENGINE - Power ISO 14396, kW:
36.8 kW
DIESEL ENGINE - Power ISO 14396, rpm:
2,700 rpm
DIESEL ENGINE - Power SAE J1995, HP:
50.1 hp
DIESEL ENGINE - Power SAE J1995, kW:
37.4 kW
DIESEL ENGINE - Power SAE J1995, rpm:
2,700 rpm
DRUM DIMENSIONS - Drum diameter, front:
35.4 in
DRUM DIMENSIONS - Drum thickness, front:
0.7 in
DRUM DIMENSIONS - Drum type, front:
Smooth/non-split
DRUM DIMENSIONS - Drum width, front:
51.2 in
DRUM DIMENSIONS - Track offset, left:
0 in
DRUM DIMENSIONS - Track offset, right:
2 in
MACHINE DIMENSIONS - Center distance:
76.8 in
MACHINE DIMENSIONS - Ground clearance, center:
12 in
MACHINE DIMENSIONS - Maximum working width:
52.7 in
MACHINE DIMENSIONS - Total height with cab:
107.1 in
MACHINE DIMENSIONS - Total height with ROPS:
102 in
MACHINE DIMENSIONS - Total length:
116.7 in
MACHINE DIMENSIONS - Total width:
56.1 in
MACHINE DIMENSIONS - Turning radius, inside:
105.9 in
SOUND LEVEL - Acoustic power LW(A), measured:
102 db(A)
SOUND LEVEL - Sound power level L(WA), guaranteed:
106
STEERING - Oscillation angle +/-:
8 °
STEERING - Steering, type:
Articulated steering
TANK CAPACITY/FILLING CAPACITY - Additive tank, capacity:
4.8 gal
TANK CAPACITY/FILLING CAPACITY - Fuel tank, capacity:
19.3 gal
TANK CAPACITY/FILLING CAPACITY - Water tank, capacity:
75.3 gal
TIRE DIMENSIONS - Number of tires, rear:
4
TIRE DIMENSIONS - Tire size, rear:
10.5/80-16
TIRE DIMENSIONS - Width over tires, rear:
50.2 in
TRAVEL DRIVE - Climbing ability, with vibration:
30
TRAVEL DRIVE - Climbing ability, without vibration:
40 %
TRAVEL DRIVE - Speed, infinitely variable:
0,0 - 6,8
VIBRATION - Amplitude, front, I:
0.02 in
VIBRATION - Amplitude, front, II:
0.012 in
VIBRATION - Centrifugal force, front, I:
14,400 lbs
VIBRATION - Centrifugal force, front, II:
8,775 lbs
VIBRATION - Vibration frequency, front, I:
3,600 VPM
VIBRATION - Vibration frequency, front, II:
3,060 VPM
WATER-SPRINKLING SYSTEM - Water sprinkling, type:
Pressure
WEIGHTS - Axle load, front:
4,675 lbs
WEIGHTS - Axle load, rear:
3,958 lbs
WEIGHTS - Empty weight without cab, without ROPS:
7,927 lbs
WEIGHTS - Operating weight with cab:
9,184 lbs
WEIGHTS - Operating weight with ROPS:
8,633 lbs
WEIGHTS - Static linear load, front:
91.3 lbs/in
