HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT
HD 10i VT

Highlights

  • Simple, intuitive and language-neutral operation
  • Easy transport, simple loading
  • Ergonomic driver platform
  • Excellent view of the drum edges, the machine and the construction site surroundings
  • Compact dimensions

Specifications

Acoustic power LW(A), measured:
102 db(A)
Acoustic power LW(A), sticker:
106
Additive tank, capacity:
18 l
Amplitude, front, II:
0.45 mm
Centrifugal force, front, I:
43 kN
Centrifugal force, front, II:
26 kN
Climbing ability, with vibration:
30
Climbing ability, without vibration:
40 %
Curb clearance, rear:
570 mm
Description:
Tandem roller with vibrating roller drum and set of tyres
Drum diameter, front:
720 mm
Drum thickness, front:
15 mm
Drum width, front:
1,000 mm
Exhaust emissions category:
EU Stage V / EPA Tier 4
Exhaust gas after-treatment:
DOC-DPF
French classific., data/class:
12,1/PV2
Fuel tank, capacity:
42 l
Height loading, min.:
1,752 mm
Max. working width:
1,050 mm
Name:
HD 10i VT
Number of cylinders:
3
Number of tyres, rear:
4
Operating weight with ROPS:
2,385 kg
Operating weight, max.:
3,110 kg
Oscillation angle +/-:
8 °
Power ISO 14396, HP:
32.6 HP
Power ISO 14396, kW:
24 kW
Power SAE J1995, HP:
32.2 hp
Power SAE J1995, rpm:
2,200 rpm
Series:
H251
Series:
HD CompactLine
Size of tyres, rear:
205/60-R15
Speed, infinitely variable:
9.6
Static linear load, front:
12.1 kg/cm
Total height with ROPS:
2,475 mm
Total length:
2,530 mm
Total width:
1,110 mm
Track offset, left:
0 mm
Track offset, right:
50 mm
Turning radius, inside:
2,470 mm
Version:
D1803-CR
Vibration frequency, front, I:
65 Hz
Vibration frequency, front, II:
51 Hz
Water tank, capacity:
180 l
Wheel base:
1,700 mm
