Hamm HD 12 VT
![Hamm](/files/download/image/600x0/fixed_width/c508ba45-0cca-4f74-8a86-bb44a78e2eee.jpeg)
![Hamm](/files/download/image/600x0/fixed_width/9e20c60c-314e-407b-960e-2d2fa8f90517.jpeg)
![Hamm](/files/download/image/600x0/fixed_width/a25841ca-a673-4f7f-ab84-ae161e3c2cf3.jpeg)
![Hamm](/files/download/image/600x0/fixed_width/f73600ec-f7aa-4d5a-aec0-631dbe8a2b89.jpeg)
![Hamm](/files/download/image/600x0/fixed_width/d377972c-16ba-4670-bee9-112628f7aaf3.jpeg)
![Hamm](/files/download/image/600x0/fixed_width/d7799cad-0d8d-4a8f-a2cc-c899ec265db1.jpeg)
![Hamm](/files/download/image/600x0/fixed_width/19fba360-2e78-4be3-a597-f985c71f95a4.png)
![Hamm](/files/download/image/600x0/fixed_width/ff9278af-c9d6-4357-a2a4-f50d8e41dbe4.jpeg)
Make | Hamm |
Model | HD 12 VT |
Type | Series HD CompactLine |
How can we help?
Description
Highlights
-
Ergonomic driver platform
-
Compact dimensions
-
Excellent view of drum edge, machine and construction site environment
-
Simple transport, simple loading
-
Simple, intuitive and language-neutral control
Specifications
- BASIC DATA - Description: Tandem roller with vibrating roller drum and set of wheels
- BASIC DATA - Exhaust emissions category: EU Stage V / EPA Tier 4
- BASIC DATA - Name: HD 12 VT
- BASIC DATA - Series: H230
- DIESEL ENGINE - Cylinders, quantity: 3
- DIESEL ENGINE - Exhaust emission standard: EU Stage V / EPA Tier 4
- DIESEL ENGINE - Exhaust gas after-treatment: -
- DIESEL ENGINE - Manufacturer: KUBOTA
- DIESEL ENGINE - Model: D1703-M-DI-E4B
- DIESEL ENGINE - Power ISO 14396, HP: 24.8 HP
- DIESEL ENGINE - Power ISO 14396, kW: 18.2 kW
- DIESEL ENGINE - Power ISO 14396, rpm: 2,200 rpm
- DRUM DIMENSIONS - Drum diameter, front: 28.3 in
- DRUM DIMENSIONS - Drum thickness, front: 0.6 in
- DRUM DIMENSIONS - Drum type, front: Smooth/non-split
- DRUM DIMENSIONS - Drum width, front: 47.2 in
- DRUM DIMENSIONS - Track offset, left: 0 in
- DRUM DIMENSIONS - Track offset, right: 2 in
- MACHINE DIMENSIONS - Center distance: 66.9 in
- MACHINE DIMENSIONS - Curb clearance, left: 22.4 in
- MACHINE DIMENSIONS - Curb clearance, rear: 22.4 in
- MACHINE DIMENSIONS - Ground clearance, center: 11 in
- MACHINE DIMENSIONS - Maximum working width: 48 in
- MACHINE DIMENSIONS - Total height with ROPS: 97.4 in
- MACHINE DIMENSIONS - Total length: 99.6 in
- MACHINE DIMENSIONS - Total width: 51.6 in
- MACHINE DIMENSIONS - Turning radius, inside: 93.3 in
- SOUND LEVEL - Acoustic power LW(A), measured: 104 db(A)
- SOUND LEVEL - Sound power level L(WA), guaranteed: 106
- STEERING - Oscillation angle +/-: 8 °
- STEERING - Steering, type: Articulated steering
- TANK CAPACITY/FILLING CAPACITY - Additive tank, capacity: 4.8 gal
- TANK CAPACITY/FILLING CAPACITY - Fuel tank, capacity: 11.1 gal
- TANK CAPACITY/FILLING CAPACITY - Water tank, capacity: 47.6 gal
- TIRE DIMENSIONS - Number of tires, rear: 4
- TIRE DIMENSIONS - Tire size, rear: 9,5/65-15
- TIRE DIMENSIONS - Width over tires, rear: 44.9 in
- TRAVEL DRIVE - Climbing ability, with vibration: 30
- TRAVEL DRIVE - Climbing ability, without vibration: 40 %
- TRAVEL DRIVE - Speed, infinitely variable: 6.0
- VIBRATION - Amplitude, front, I: 0.018 in
- VIBRATION - Amplitude, front, II: 0.018 in
- VIBRATION - Centrifugal force, front, I: 8,550 lbs
- VIBRATION - Centrifugal force, front, II: 5,175 lbs
- VIBRATION - Vibration frequency, front, I: 3,900 VPM
- VIBRATION - Vibration frequency, front, II: 3,060 VPM
- WATER-SPRINKLING SYSTEM - Water sprinkling, type: Pressure
- WEIGHTS - Operating weight with ROPS: 5,722 lbs
- WEIGHTS - Static linear load, front: 62.7 lbs/in
