317G Compact Track Loader
  • Rated Operating Capacity: 965 kg (2,125 lb.)
  • Gross Horsepower: 48.5 kW (65 hp)
  • Net Horsepower: 45.6 kW (61 hp)
  • Operating Weight: 3,824 kg (8,423 lb.)

Features

  • GROSS HORSEPOWER: 48.5 kW (65 hp)

  • BUCKET BREAKOUT FORCE: 1,930 kg (4,250 lb.)

  • LIFT HEIGHT: 3.07 m (121.0 in.)(10 ft. 1 in.)

  • RATED OPERATING CAPACITY: 965 kg (2,125 lb.)

  • OPERATING WEIGHT: 3,824 kg (8,423 lb.)

  • NET HORSEPOWER: 45.6 kW (61 hp)

Specifications

CAPACITIES - Fuel Tank, ltr (gallons (US)):
71 (19)
DESCRIPTION - Lift Geometry:
Vertical
DIMENSIONS - Dump Angle, Degrees:
42
DIMENSIONS - Dump Height - Maximum Foundry, mm (inches):
2430 (95.6)
DIMENSIONS - Ground Clearance, mm (inches):
210 (8.3)
DIMENSIONS - Height - Top Of Cab, mm (inches):
1990 (78.5)
DIMENSIONS - Height to Hinge Pin, mm (inches):
3070 (121)
DIMENSIONS - Length - Foundry Bucket, mm (inches):
3240 (127.6)
DIMENSIONS - Length - No Bucket, mm (inches):
2630 (103)
DIMENSIONS - Rear Departure Angle, Degrees:
32.3
DIMENSIONS - Rollback - Ground Level, Degrees:
30
DIMENSIONS - Track Gauge, mm (inches):
1330 (52.5)
DIMENSIONS - Width - No Bucket, mm (inches):
1650 (65.1)
DRIVELINE - Aspiration:
Turbo
DRIVELINE - Displacement, ltr (Inches³):
2.1 (128)
DRIVELINE - Emission Rating:
Tier 4 / Stage IV
DRIVELINE - Engine Manufacturer :
Yanmar
DRIVELINE - Engine Model:
4TNV86CHT
DRIVELINE - Engine Output - Gross, kW (hp):
48.5 (65)
DRIVELINE - Engine Output - Net, kW (hp):
45.6 (61)
DRIVELINE - Rated Speed, rpm:
2600
DRIVELINE - Torque, Nm (lbf / ft):
207 (153)
DRIVELINE - Track Shoe Width, mm (inches):
320 (12.6)
PERFORMANCE - Breakout - Bucket Foundry, kN (lbf):
26.6 (6000)
PERFORMANCE - Breakout - Lift Foundry, kN (lbf):
23.3 (5250)
PERFORMANCE - Ground Bearing Pressure - Foundry, kPa (PSI):
38 (5.5)
PERFORMANCE - Hydraulic Power, kW (hp):
24.729 (33.1)
PERFORMANCE - Pump Flow, lt/min (gallons (US) / min):
63 (17)
PERFORMANCE - Rated Operating Capacity - Foundry, kg (lbs):
965 (2125)
PERFORMANCE - Speed - Maximum, kph (mph):
11.3 (7)
PERFORMANCE - System Pressure, bar (PSI):
237.87 (3450)
PERFORMANCE - Tipping Load - Foundry, kg (lbs):
2756 (6070)
WEIGHTS - Operating Weight - Foundry, kg (lbs):
3824 (8423)

Engine

Final Tier 4 (FT4)/EU Stage IV diesel engine packs plenty of power and torque.

Auxiliary flow rates make the most of an even broader range of attachments.

Large coolers increase heat rejection for uninterrupted performance in severe, high-load conditions. Engine-mounted, belt-driven cooling fan delivers efficient, reliable performance.

Stability

Equipped with optional 15.8-inch-wide track, this CTL’s ground pressure is just 4.5 psi, enabling work in soft underfoot conditions and side-slope stability.

Vertical Lift Boom

The vertical-lift boom offers more lift height and reach at the top of the lift path, for more stability and truck-loading ability.

Cab & Controls

Electrohydraulic (EH) joysticks are standard.

Excellent all-around visibility is further enhanced with an LED side-lighting option.

Optional rearview camera allows operators to see the jobsite behind the machine.

Serviceability

Swing-out rear door enables easy, ground-level access to daily service checkpoints and cooling system components.

Hinged rear door and hydraulic cooler swing open, making trash removal and core cleanout simple.

Spin-on engine oil and fuel filers mounted remotely behind the rear door allow quick changes.
