John Deere 910G Forwarder
Forwarders
How can we help?
(208) 324-2900
Features
-
Boom Reach: 9.8 m (32.2 ft.) / 8.5 m (27.9 ft.) / 10 ft. (32.8 ft.)
-
Engine Power: 118 kW (160 hp) at 1,900 rpm
-
Gross Lifting Torque: 76 kNm (56,000 ft.-lb.)  / 102 kNm (75,000 ft.-lb.)
-
Tractive Force: 150 kN (33,721 lbf.) with 24.5 tires /  110 kN (24,729 lbf.) with 22.5 tires
-
Gross Slewing Torque: 19 kNm (14,000 ft.-lb.) / 24 kNm (18,000 ft.-lb.)
-
Load Rating: 9000 kg (19,842 lb.)
Specifications
CAPACITIES - Alternator Output, Amp: |
150 |
CAPACITIES - Fuel Tank, ltr (gallons (US)): |
150 (39.6) |
CAPACITIES - Hydraulic Tank, ltr (gallons (US)): |
150 (39.6) |
DIMENSIONS - Base Carrier Length, mm (inches): |
9055 (356.4) |
DIMENSIONS - Ground Clearance, mm (inches): |
638 (25) |
DIMENSIONS - Height Over Cab, mm (inches): |
3685 (145.2) |
DIMENSIONS - Horizontal Reach, m (ft/in): |
9.6 (32 ft 2 in) |
DIMENSIONS - Load Length, mm (inches): |
4090 (160.8) |
DIMENSIONS - Transport Height, mm (inches): |
3685 (145.2) |
DIMENSIONS - Wheelbase, mm (inches): |
4800 (188.4) |
DIMENSIONS - Width - Fixed Bunk, mm (inches): |
2500 (98.4) |
DIMENSIONS - Width, mm (inches): |
2780 (109.2) |
DRIVELINE - Displacement, ltr (Inches³): |
4.5 (274.6) |
DRIVELINE - Drive Configuration: |
8 x 8 |
DRIVELINE - Engine Manufacturer : |
John Deere |
DRIVELINE - Engine Model: |
PowerTech Plus 4045 |
DRIVELINE - Engine Output, kW (hp): |
118 (158) |
DRIVELINE - Engine Torque, Nm (lbf / ft): |
650 (479.4) |
DRIVELINE - Std tire size front: |
700 x 24.5 |
DRIVELINE - Std tire size rear: |
700 x 24.5 |
DRIVELINE - Transmission: |
Hydrostatic-Mechanical |
PERFORMANCE - Lifting Moment - Standard Crane, kNm (lbf / ft): |
76 (56) |
PERFORMANCE - Load Capacity, tonnes (tons (short)): |
10 (22046) |
PERFORMANCE - Pump Capacity, cm³ (Inches³): |
120 (7.3) |
PERFORMANCE - System Voltage, V: |
24 |
PERFORMANCE - Tractive Force, kN (lbf): |
110 (33721) |
PERFORMANCE - Travel Speed, kph (mph): |
23 (14.3) |
WEIGHTS - Operating Weight, kg (lbs): |
14950 (32959) |
Short-Wheelbase
Available with a 40-cm-shorter wheelbase, for better agility in thinnings, without compromising stability or load size.
Compact Design
Ideal for early to late thinning operations, the compact dimensions of the 910G maximizes productivity and power in the most demanding conditions.
Intelligent Boom Control
- Optional Intelligent Boom Control eases boom operations, making them more precise and productive.
- Joysticks are configurable to user preference, so operators can run IBC using their preferred control patter.
Self-Leveling Cab
Rotating, self-leveling cab turns 290 deg. for an all-around view of boom movements and the jobsite, for safe, efficient log loading.
