Highlights

  • 2 in 1: Crushing and compacting in one process
  • 3-point articulation for outstanding traction and off-road mobility
  • Simple tool changing thanks to patented holder exchange system
  • High crushing force owing to high point load
  • High flexibility – use for standard and special applications

Features

  • HAMMTRONIC: HAMMTRONIC is an electronic machine management system that monitors and controls all key machine functions, thereby increasing safety, economy and fuel savings. The opportunities offered by HAMMTRONIC include, for instance, automatic adjustment of the diesel engine speed to meet the power requirements of the individual drives. Moreover, HAMMTRONIC controls start-up and braking, and distributes the drive torques across the drum axis and back wheels in line with current operating data. HAMMTRONIC also controls the hydrostatic vibration drive and the various steering programmes (for DV+ series only), guaranteeing even, smooth movement of both drums. HAMMTRONIC is an electronic machine management system that monitors and controls all key machine functions, thereby increasing safety, economy and fuel savings. The opportunities offered by HAMMTRONIC include, for instance, automatic adjustment of the diesel engine speed to meet the power requirements of the individual drives. Moreover, HAMMTRONIC controls start-up and braking, and distributes the drive torques across the drum axis and back wheels in line with current operating data. HAMMTRONIC also controls the hydrostatic vibration drive and the various steering programmes (for DV+ series only), guaranteeing even, smooth movement of both drums.

  • 3-point articulation: 3-point articulation is different to conventional joints due to its geometric arrangement and connection of the three individual joints and one additional connecting link between the two conventional upper joints. This allows optimum steering, excellent driving safety and maximum driving comfort. 3-point articulation is different to conventional joints due to its geometric arrangement and connection of the three individual joints and one additional connecting link between the two conventional upper joints. This allows optimum steering, excellent driving safety and maximum driving comfort.

  • Easy Drive: Simple and intuitive operation is becoming increasingly important for state-of-the-art construction machinery. With Easy Drive, HAMM has, therefore, developed a standardised operating concept for tandem rollers (HD+ and DV+ series), compactors (H series) and pneumatic tyre rollers (HP series) that reduces complexity to a minimum and enables operators to react quickly and correctly in no time at all. Alongside its clear, intuitive, easy to learn operating concept, Easy Drive comprises a range of features that improve ergonomic, safety-related and service-related characteristics. Simple and intuitive operation is becoming increasingly important for state-of-the-art construction machinery. With Easy Drive, HAMM has, therefore, developed a standardised operating concept for tandem rollers (HD+ and DV+ series), compactors (H series) and pneumatic tyre rollers (HP series) that reduces complexity to a minimum and enables operators to react quickly and correctly in no time at all. Alongside its clear, intuitive, easy to learn operating concept, Easy Drive comprises a range of features that improve ergonomic, safety-related and service-related characteristics.

  • HAMM Compaction Quality (HCQ): HCQ comprises a number of HAMM products designed to measure, monitor, document and control compaction and compaction processes. This includes the HAMM Compaction Meter, the HAMM Temperature Meter and the HCQ Navigator. These components continue to determine the rigidity value, the asphalt temperature and the position of the roller throughout compaction. An panel PC (touchscreen) on the driver's platform then visualises the entire data package in the form of a real-time "compaction map" and shows the roller operator where has already been sufficiently compacted and where further passes are still required. The WITOS HCQ Navigator process module also allows you to follow the construction site progress worldwide in real time. HCQ comprises a number of HAMM products designed to measure, monitor, document and control compaction and compaction processes. This includes the HAMM Compaction Meter, the HAMM Temperature Meter and the HCQ Navigator. These components continue to determine the rigidity value, the asphalt temperature and the position of the roller throughout compaction. An panel PC (touchscreen) on the driver's platform then visualises the entire data package in the form of a real-time "compaction map" and shows the roller operator where has already been sufficiently compacted and where further passes are still required. The WITOS HCQ Navigator process module also allows you to follow the construction site progress worldwide in real time.

Specifications

Acoustic power LW(A), measured:
105 db(A)
Acoustic power LW(A), sticker:
106
AdBlue/DEF tank, content:
32 l
Amplitude, front:
2.09 mm
Axle load, front:
16,770 kg
Axle load, rear:
8,490 kg
Centrifugal force, front:
351 kN
Climbing ability, with vibration:
61
Climbing ability, without vibration:
66 %
Description:
Compactor with vibration crusher drum
Drum diameter, front:
1,710 mm
Drum thickness, front:
35 mm
Drum width, front:
2,220 mm
Exhaust emissions category:
EU Stage V / EPA Tier 4
Exhaust gas after-treatment:
DOC-DPF-SCR
French classific., data/class:
109,2/VPM5
Fuel tank, capacity:
280 l
Ground clearance, centre:
400 mm
Height loading, min.:
2,320 mm
Name:
H 25i VC
Number of cylinders:
6
Number of tyres, rear:
2
Operating weight with cab:
25,260 kg
Operating weight, max.:
25,650 kg
Oscillation angle +/-:
10 °
Power ISO 14396, HP:
217.6 HP
Power SAE J1349, HP:
214.4 hp
Power SAE J1349, kW:
160 kW
Power SAE J1349, rpm:
2,300 rpm
Series:
H
Series:
H268
Size of tyres, rear:
EM 23.5-R25 XTLA
Slope angle, front:
40 °
Slope angle, rear:
28 °
Speed, infinitely variable:
0 - 8,0
Tool holder, quantity:
150
Total height with cab:
2,970 mm
Total length:
6,751 mm
Total width with cab:
2,540 mm
Turning radius, inside:
4,760 mm
Version:
TCD 6.1 L6
Vibration frequency, front:
27 Hz
Wheel base:
3,261 mm
Width over tyres, rear:
2,160 mm
