Highlights

  • 3-point articulation for outstanding traction and off-road mobility
  • Compaction system VIO – vibration or oscillation
  • Excellent view of the machine and the construction site
  • Electronic machine management Hammtronic
  • Operating concept Easy Drive

Features

  • Easy Drive: Simple and intuitive operation is becoming increasingly important for state-of-the-art construction machinery. With Easy Drive, HAMM has, therefore, developed a standardised operating concept for tandem rollers (HD+ and DV+ series), compactors (H series) and pneumatic tyre rollers (HP series) that reduces complexity to a minimum and enables operators to react quickly and correctly in no time at all. Alongside its clear, intuitive, easy to learn operating concept, Easy Drive comprises a range of features that improve ergonomic, safety-related and service-related characteristics. Simple and intuitive operation is becoming increasingly important for state-of-the-art construction machinery. With Easy Drive, HAMM has, therefore, developed a standardised operating concept for tandem rollers (HD+ and DV+ series), compactors (H series) and pneumatic tyre rollers (HP series) that reduces complexity to a minimum and enables operators to react quickly and correctly in no time at all. Alongside its clear, intuitive, easy to learn operating concept, Easy Drive comprises a range of features that improve ergonomic, safety-related and service-related characteristics.

  • Oscillation: In an oscillation drum, two eccentric shafts are fitted at a 180° angle to each other. Both unbalanced masses rotate synchronously, which causes the drum to perform a rapidly alternating forwards-backwards rotational movement. This results in the compaction energy being transmitted forwards and backwards tangentially into the ground below in the form of shear forces. The oscillation system developed by HAMM achieves compaction results that are scientifically proven to be more homogeneous and higher quality, leading to faster, more significant compaction increases. The scope of application is enormous. In an oscillation drum, two eccentric shafts are fitted at a 180° angle to each other. Both unbalanced masses rotate synchronously, which causes the drum to perform a rapidly alternating forwards-backwards rotational movement. This results in the compaction energy being transmitted forwards and backwards tangentially into the ground below in the form of shear forces. The oscillation system developed by HAMM achieves compaction results that are scientifically proven to be more homogeneous and higher quality, leading to faster, more significant compaction increases. The scope of application is enormous.

  • 3-point articulation: 3-point articulation is different to conventional joints due to its geometric arrangement and connection of the three individual joints and one additional connecting link between the two conventional upper joints. This allows optimum steering, excellent driving safety and maximum driving comfort. 3-point articulation is different to conventional joints due to its geometric arrangement and connection of the three individual joints and one additional connecting link between the two conventional upper joints. This allows optimum steering, excellent driving safety and maximum driving comfort.

  • HAMMTRONIC: HAMMTRONIC is an electronic machine management system that monitors and controls all key machine functions, thereby increasing safety, economy and fuel savings. The opportunities offered by HAMMTRONIC include, for instance, automatic adjustment of the diesel engine speed to meet the power requirements of the individual drives. Moreover, HAMMTRONIC controls start-up and braking, and distributes the drive torques across the drum axis and back wheels in line with current operating data. HAMMTRONIC also controls the hydrostatic vibration drive and the various steering programmes (for DV+ series only), guaranteeing even, smooth movement of both drums. HAMMTRONIC is an electronic machine management system that monitors and controls all key machine functions, thereby increasing safety, economy and fuel savings. The opportunities offered by HAMMTRONIC include, for instance, automatic adjustment of the diesel engine speed to meet the power requirements of the individual drives. Moreover, HAMMTRONIC controls start-up and braking, and distributes the drive torques across the drum axis and back wheels in line with current operating data. HAMMTRONIC also controls the hydrostatic vibration drive and the various steering programmes (for DV+ series only), guaranteeing even, smooth movement of both drums.

  • HAMM Compaction Quality (HCQ): HCQ comprises a number of HAMM products designed to measure, monitor, document and control compaction and compaction processes. This includes the HAMM Compaction Meter, the HAMM Temperature Meter and the HCQ Navigator. These components continue to determine the rigidity value, the asphalt temperature and the position of the roller throughout compaction. An panel PC (touchscreen) on the driver's platform then visualises the entire data package in the form of a real-time "compaction map" and shows the roller operator where has already been sufficiently compacted and where further passes are still required. The WITOS HCQ Navigator process module also allows you to follow the construction site progress worldwide in real time. HCQ comprises a number of HAMM products designed to measure, monitor, document and control compaction and compaction processes. This includes the HAMM Compaction Meter, the HAMM Temperature Meter and the HCQ Navigator. These components continue to determine the rigidity value, the asphalt temperature and the position of the roller throughout compaction. An panel PC (touchscreen) on the driver's platform then visualises the entire data package in the form of a real-time "compaction map" and shows the roller operator where has already been sufficiently compacted and where further passes are still required. The WITOS HCQ Navigator process module also allows you to follow the construction site progress worldwide in real time.

Specifications

Acoustic power LW(A), measured:
104 db(A)
Acoustic power LW(A), sticker:
105
AdBlue/DEF tank, content:
32 l
Axle load, front:
6,865 kg
Axle load, rear:
5,745 kg
Climbing ability, with vibration:
52
Climbing ability, without vibration:
57 %
Description:
Compactor with VIO-drum
Drum diameter, front:
1,504 mm
Drum thickness, front:
30 mm
Drum width, front:
2,140 mm
Exhaust emissions category:
EU Stage V / EPA Tier 4
Exhaust gas after-treatment:
DOC-DPF-SCR
French classific., data/class:
44,0/VM3
Fuel tank, capacity:
280 l
Ground clearance, centre:
390 mm
Height loading, min.:
2,308 mm
Name:
H 13i VIO
Number of cylinders:
4
Number of tyres, rear:
2
Operating weight with cab:
12,610 kg
Operating weight with ROPS:
12,350 kg
Operating weight, max.:
15,620 kg
Oscillation angle +/-:
10 °
Power ISO 14396, HP:
156.4 HP
Power SAE J1349, HP:
154.1 hp
Power SAE J1349, kW:
115 kW
Power SAE J1349, rpm:
2,300 rpm
Series:
H
Series:
H267
Size of tyres, rear:
AW 23.1-26 12 PR
Slope angle, front:
53 °
Slope angle, rear:
32 °
Speed, infinitely variable:
0 - 12,0
Total height with cab:
2,960 mm
Total length:
5,850 mm
Total width with cab:
2,284 mm
Turning radius, inside:
3,870 mm
Version:
TCD 4.1 L4
Wheel base:
3,150 mm
Width over tyres, rear:
2,160 mm
